SFP Module 1G MM Duplex 550M | eSFP-GE-SX-MM850

Name: SFP Module 1G MM Duplex 550M | eSFP-GE-SX-MM850
Brand: Viskou | One-Stop Tech Solutions for a Smarter Future
SKU: 02315204
Price: 300 MYR
Availability: InStock

eSFP-GE-SX-MM850

- Extinction ratio (dB) is ≥ 9
- Transmit power (dBm) is -9.5 to -2.5
- Maximum receiver sensitivity (dBm) is -17

RM300.00 ~~RM600.00~~

(Excluding Taxes)

Quantity

-

+

4 In Stock, Puchong

2 In Stock, Johor Bahru

0 In Stock, Penang (Perai)

0 In Stock, Penang (Gelugor)

10 In Stock, KK

Add to Favorite Items

Description

eSFP-GE-SX-MM850
SFP Module 1G MM Duplex 550M

Extinction ratio (dB) is ≥ 9
Transmit power (dBm) is -9.5 to -2.5
Maximum receiver sensitivity (dBm) is -17

Specifications

Part number	02315204
Version support	Supported in V100R001C00 and later versions
Transceiver form factor	eSFP
Transmission speed	GE
Center wavelength (nm)	850
Standards compliance	1000BASE-SX
Connector type	LC
Type of the end face of the fiber ceramic ferrule	PC or UPC
Applicable cable and maximum transmission distance	Multimode fiber (with diameter of 62.5 μm): 220 m Multimode fiber (OM1) (with diameter of 62.5 μm): 275 m Multimode fiber (with diameter of 50 μm): 500 m Multimode fiber (OM2) (with diameter of 50 μm): 550 m

Datasheet

Download Datasheet
